Differential Pressure Switch DPS
Pressure measurement›Pressure switches

Differential Pressure Switch DPS

The DPS is a differential pressure switch designed by Neodyn for harsh conditions, offering high resistance to temperature and pressure. Ideal for monitoring filters, pumps, and hydraulic systems, it allows easy adjustment of the desired pressure using the adjustment screw located inside the device. With an adjustment range from 400 to 1000 mm CE (3 to 500 psi) and connections available in BSP, NPT, PT, or M20x1.5, it adapts to all configurations. Equipped with one or two SPDT contacts (15 A) and a robust aluminum housing, the DPS withstands temperatures up to 205 °C and pressures up to 1000 psi. With an IP66 protection rating, it is perfectly suited for outdoor environments and demanding applications in the oil, chemical, and water treatment industries.

Technical Details

Connection1/4"...1/2" BSP, NPT, PT, M 20x1.5
Adjustment Range400...1000 mm H2O, 3....500 psi
Output1 or 2 SPDT Contacts (Same Set Value)
Contact Value15A 125/250 VAC, DC125V 0.4A, DC30V 3A
EnclosureAluminum
Temperature~30...+205°C
Wet PartsAIS1316
ProtectionIP66
Pressure Resistance1000 Psi max.
Get Product
Download CatalogContact Expert

Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.

For more information about this product, download the catalog.
