Insertion Vortex Flowmeter - FBVP
Flow measurement›Vortex flow measurement

Insertion Vortex Flowmeter - FBVP

The FBVP series insertion vortex flow meters are easy-to-maintain flow meters with no moving parts. They come equipped with a standard display, electrical outputs, and optional serial communication for simple monitoring and control. The materials used in their construction make them suitable for a wide range of chemical fluids. They are ideal for demineralized water systems as well as for gas and steam measurement. Thanks to pressure and temperature compensation, they provide accurate mass flow measurements.

Technical Details

Measuring Range-Liquid0,3...7 m/sn
Measurement Range for Gas2...60 m/sn
Connection SizeDN200...DN1000
Wet PartsAISI304, Ops. AISI316
Temperature250°C max Ops. 350°C
Pressure16 Bar max. Ops 40 Bar veya 100 Bar
Accuracy<±0,75% O.D. ve ± 1 % O.D.
ProtectionIP67 Ops. Ex d IIC T3 Gb
Get Product
Download CatalogContact Expert

Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.

For more information about this product, download the catalog.
