NEO-FX330 Vortex Flow Meter
Flow measurement›Vortex flow measurement

NEO-FX330 Vortex Flow Meter

The FX330 is an easy-to-use vortex flowmeter designed for volumetric and mass flow measurement of steam, gases, and liquids. Using the Kármán vortex shedding principle, it offers a reliable and maintenance-free solution for industrial applications requiring versatile measurement. Available in flanged (DN15 to DN300) and sandwich (DN15 to DN100) versions, it provides not only flow but also density, temperature, pressure, and heat energy with optional sensors. With accuracy of ±0.75 % for liquids and ±1 % for steam and gases, and 4-20 mA HART, pulse, and digital outputs, the NEO-FX330 integrates easily into any automation system. Ideal for the chemical, petrochemical, power generation, and food and beverage industries.

Technical Details

Nominal size flanged versionDN15 to DN300 (½" to 12")
Nominal size sandwich versionDN15 to DN100 (½" to 4")
Process valuesVolume flow, mass flow, corrected volume flow, density, temperature, pressure, heat energy
AccuracySteam and gases: +/- 1%, Liquids: +/- 0.75%
Current output4 - 20 mA HART (loop powered)
Digital outputPulse (max. 1000 Hz), frequency, status, limit switch
CommunicationHART 7, Profibus PA and Foundation Fieldbus in preparation
Get Product
Download CatalogContact Expert

Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.

For more information about this product, download the catalog.
