NEO-MPS100 SITRANS Miniature Pressure Transmitter
Pressure measurement›Pressure Transmitters

NEO-MPS100 SITRANS Miniature Pressure Transmitter

The MPS100 is a miniature pressure transmitter specially designed for installations with limited mounting space, particularly valued by machine and industrial equipment manufacturers. Despite its compact size, it offers reliable performance for gauge or absolute pressure measurement, with ranges from 0-100 mbar to 0-600 bar. Available with G1/4" to G1/2" and NPT connections, it adapts to all hydraulic and pneumatic configurations. Its ceramic or SS316L diaphragm ensures excellent chemical compatibility. With standard ≤ 1 % or optional 0.5 % accuracy, 4-20 mA or 0-10 VDC outputs, and IP65, IP67, or IP68 protection, the NEO-MPS100 is the ideal solution for machine tools, robotics, hydraulics, and demanding industrial applications where space is critical.

Technical Details

ConnectionG1/4"...G1/2", 1/4" NPT, 1/2" NPT
Measurement Range0...100m Bar-0..600 Bar
Output4-20 mA, 0-10 VDC
Pressure<=1% F.S Ops. 0.5
DiaphragmCeramic, SS316L
Supply10...32VDC
Temperature-40°C...+125°C
ProtectionIP65,IP67,IP68
Get Product
Download CatalogContact Expert

Our expert team is ready to guide you in selecting the perfect measurement instruments for your applications.

For more information about this product, download the catalog.
